FEATURES :

• Max Machine Speed for thermoform – Maximum output of 240 blister / min.
• Max forming area - 110 x 210
• Min. Pack Size - 26 x 58
• Optimum Forming Depth - 12 mm
• Max Reel Diameter (Base foil) - 440
• Max Reel Diameter (Lid foil) - 210
• Max Base foil width - 218
• Max lidding foil width - 214
• Max Cone Diameter - 70-76mm

UTILITIES :

• Connected Load (kw) - 8KW
• Average Power Consumption - 3KW
• Approx 3 Phase power supply - 4 wire + Protective
• (415V + 10%) - Earthing
• Cooling water Cosumption - 46- 60 Ltr/hr
• Compressed Air - 8 CFM
• Net Weight Approx - 1400 KG

MACHINE DIMENSION (in mm) :

• Machine Length - 3200 + 2%
• Machine Width - 3100 + 2%
• Machine Height - 1900 + 2%

FLOOR DIMENSION (in mm)

• Machine Length - 4000 + 2%
• Machine Width - 3100 + 2%
• Machine Height - 2400 + 2%
