FORMAT RANGE :

• Maximum Forming Area – 200mm x 120 mm
• Maximum Base Foil Width – 210 mm
• Maximum Lidding-Foil Width – 210 mm
• Maximum Forming Depth – 12mm

FEATURES :

• Compact Lab Model Machine.
• Pneumatic Driven stations controlled by Full Automatic.
• Each station of machine is driven independently.
• Ideal machine for Blister sampling, Testing & Small Batches.
• Flat Forming, Sealing and Punching.
• Tool less change over with safety acrylic guards.
• Full stainless steel cladding conforming to GMP standard.
• User Friendly & easy to operate.
• Power consumption – Single Phase, 63 Amp.
• Compressed Air required – 6 CFM

DIMENSION OF MACHINE :

• Length : 800 mm
• Width : 550 mm
• Height : 1650 mm

WEIGHT (Net Weight – 700 Kg.)
