FEATURES :

• Pneumatic-Driven stations controlled by full function High Speed PLC.
• Each station of machine is driven independently.
• User-friendly MMI with recipes and product, library functions for quick change over.
• Alarm listing on MMI.
• Auto Feeding.
• GMP Model with Sand Blasting.
• User friendly and easy to operate.

OPTIONAL FEATURES :

• Embossing.
• Perforation.
• Servo controlled indexing of web.
• Print Registration Control [PRC].
• Printing Unit.

TECHNICAL DETAILS :

• FORMAT RANGE
• Maximum Forming Area - 140 mm x 86mm
• Maximum Base Foil Width - 148mm
• Maximum Lidding Foil Width - 148mm
• Maximum Forming Depth - 12mm

UTILITIES :

• Air Consumption - 350 Ltrs/Min at 6 Bar Pressure.
• Cooling Water Requirement - 120Ltrs/Hr at 140 C [Base Foil Dependent]
• Power Consumption - 3 Phase, 63 Amp, ELCB 3 Pole with Neutral.
• Input supply for machine - 440 Volts.

MACHINE SPEED :

• 30 strokes / min for Thermo Formed Blisters.
• 25 strokes / min for Cold Formed Blisters.

BASE FILM

• Thermoformable PVC, PVC with PE / PVDC, ACLAR, COC.
• Cold Forming Tri-Laminated Aluminum.

DIMENSION

• (L x W x H - 8'10" x 2'5" x 6'5" )

WEIGHT ( Net Weight - 1.5 Tons. )
