FEATURES :

• Pneumatic – Driven stations controlled by full function High Speed PLC.
• Cam based System.
• User-friendly MMI with recipes and product, library function for quick change over.
• Alarm listing on MMI.
• Auto Feeding.
• GMP Model with Sand Blasting.
• User friendly and easy to operate.

OPTIONAL FEATURES :

• Embossing.
• Perforation.
• Servo controlled indexing of web.
• Print Registration Control (PRC).
• Printing Unit.

TECHNICAL DETAILS :

• Maximum Forming Area – 290mm x 140mm
• Maximum Base Foil Width - 300mm
• Maximum Lidding Foil Width - 300mm
• Maximum Forming Depth - 15mm

UTILITIES :

• Air Consumption – 12 Bar Pressure.
• Cooling Water Requirement – 40-60 Ltrs/Hr at 140C (Base Foil Dependent)
• Power Consumption – 3 Phase, 63 Amp, ELCB 3 Pole with Netural.
• Input supply for machine – 440 Volts.

MACHINE SPEED :

• 40 Strokes / min for Thermo Formed Bilsters.
• 35 Strokes / min for Cold Formed Bilsters.

BASE FILM

• Thermoformable PVC, PVC with PE / PVDC, ACLAR, COC.
• Cold Forming Tri-Laminated Aluminum.

MACHINE DIMENSION (in mm)

• Machine Length - 3550
• Machine Width - 1150
• Machine Height - 1735

FLOOR DIMENSION (in mm)

• Machine Length - 4000
• Machine Width - 3100
• Machine Height - 2400

WEIGHT (Net Weight – 2 Tons.)
